HR Tested Fit and Function

2014-2020 Toyota Tundra LED Rear Turn Signal Upgrade

X.1417TUN-RER.TRNLED-HR

PART #: 2 x GTR.LED601, 1 x GTR.H111


[ In Stock: 0 pieces ]

Product Details

2014-2021 Toyota Tundra LED Rear Turn Signal Bulbs: Looking for upgraded LED Rear Turn Signal Bulbs from a reputable brand and value the fact that we've actually tested them on your truck? Our HR Tested kits include all the right components to ensure perfect fit, function, and performance from the upgrade. At Headlight Revolution, we do 2014-2021 Toyota Tundra LED lighting upgrades better!

As part of our Tundra Video Series: we showed viewers how to install LED rear red blinker light bulbs on their 2014-2018 Toyota Tundra. We supply only the highest quality LED bulbs from GTR Lighting so you won't have any headaches and they will last a long time.

You can't use just any LED bulbs: to plug into the rear parking light / turn signal position on the Tundra - these need to be specially designed to work with the Tundra wiring! We have the right bulbs!

This kit comes with everything you need to do the install: and just watch the video to see how it's done!

Kit comes with two ARMOR SERIES 7440 LED Bulbs: Direct factory replacement. No modification required. The Armor Series of LED bulb is impressively bright, with an unparalleled Black-Chrome style. The white is one of the brightest bulbs we offer, and the other colors are vibrant and impressive. The Armor series look great on and off, so if you're looking for a super bright option that also looks cool, you've found the right option! Using state of the art 2835 SMD LED chips to produce unparalleled light output with high-efficiency power usage! The focusing lens on top creates a 165-degree beam pattern output and the decorative metal style of the bulb surrounding is an excellent heat sink. This means we can push these LEDs to the limit without risk of damaging them from heat! Get ready for an amazing bulb that will last a very long time.

The circuitry in the Armor series of LED bulbs by GTR Lighting is unique: in that it will work with any OEM wiring configuration you will find. CK Style, SACK style, normal/traditional style, it will work in all socket types. This makes your life easier by having a great performing bulb that takes zero guesswork to install!

Constant Current Driver: The Armor Series of LED bulbs from GTR Lighting are built using a state of the art Constant Current Driver inside the bulb. This allows them to be more reliable when used on vehicles that have voltage fluctuations due to electrical system design or fault. A constant current driver is a device that takes any incoming voltage and smooths it out, regulates it, so a steady stream of voltage/current reaches the LED. This helps the LED bulb last longer than bulbs that don't have this device built in.

HR Tested: Here at Headlight Revolution, we've spent the time to install and test all HR Tested products, so we know it'll work exactly as shown and right out of the box! Not only that, but we don't favor one particular brand. We just deliver the best product for the application, period. Be sure to reference our install videos for helpful tips on making the installation process quick, painless, and clear. HR Tested: We ensure fitment and function. You do the install. For other compatible upgrades, use the Buyers Guide on our homepage!

Product Specs

  • What's Included

  • BULBS: 2x (One Pair)

  • RESISTORS: 2x (One Pair)

  • WARRANTY: 2 Years

  • Compatibility

  • TOYOTA TUNDRA: 2014-2020 w/ Stock Housings

  • Tech Specs

  • CHIPSET: 16x Samsung 2835

  • LENGTH: 2.06in / 52.3mm

  • DIAMETER: 0.84in /21.3mm

  • WATTAGE: 0.8w (dim) / 4.7w (bright)

  • CURRENT LOAD: 57mA (dim) / 334mA (bright)

  • RAW LUMENS: 750lm

  • EFFECTIVE LUMENS: 600lm

Product Reviews

4.9 out of 5 stars

36 Reviews   Write a Review

5 out of 5 stars

Review

Gaetano Alagna

Quick and easy thank you headlight revolution


5 out of 5 stars

Best LEDs

Addrian Reyes

Easy install, even easier with the videos provided online


5 out of 5 stars

Tail lights, front and rear blinkers and headlight

Ian Harrison

Excellent lights, thanks guys for doing all the research... Your videos instruction was invaluable.


5 out of 5 stars

Perfect..

Smyrna Gaetos

It suits the most i needed up-grade. Moneys worth.


4 out of 5 stars

The lights are great

Shannon Caldwell

The install could have been better if HR had labeled the individual lights per their application. I ordered every light on my 2018 Tundra and non of them were labeled as to their application. I had to go back and watch videos, look on the website and still could only figure out a couple. The part numbers on the packaging are not used on the online description or the packing list, there was literally no way to cross reference. I truly appreciate HR figuring which bulbs are for which application so all I have to do is order the bulbs, but they didn't finish the job, I received a box full of bulbs and there was no way to figure out which bulb went where. In the end I figured it out.


3 out of 5 stars

Issue with resistors, tough to mount, but great light

Spencer Absher

This is the second time I have purchased this upgrade kit; first time for a 2015 Tundra, this time for a 2017 Tundra. When I purchased them this time, I noticed a significant decrease in quality.

The biggest problem is the rubber insulation for the wire on the resistors is cracked so bad, it was falling off. I contacted support and they said they have a lifetime warranty so they would send me a new one, but I just decided to take a refund and get my own resistors with the same Ohm value. I don't want to have to disassemble this in the future and make another cut into the factory wiring.

Second problem, the resistors only come with a single screw for each. There are two screw holes so you can mount these to the truck (they get hot so can't be zip tied or taped) but only 2 screws total.

Lastly, the packaging for the bulbs looks like it is surplus packing and not meant for these size of bulbs.

None of this effects the quality of the bulb itself which, I never had a problem with on my old truck. Hopefully these are still good quality as I have had a LOT of other GTR lighting bulbs go out on me over the years.

Thank goodness for lifetime warranty.... :/


4 out of 5 stars

Lead wires on resistors not long enough

Travis Edwards

Good thing I can solder! Had to solder longer lead wires to the resistors so IÄôd have enough slack to mount them where they would fit. Kind of a pain.


5 out of 5 stars

Awesome and Bright

George Lowe

These lights are super bright and install was really easy thanks to the comprehensive videos.


5 out of 5 stars

Next time please write down

June Say

Next time please write down the name of the products because well someone like me have a hard time to figure it out where the products should go.:blush:


5 out of 5 stars

Rear blinker kit

Verner Nelson

Awesome lighting. I feel confident in knowing people will be able to easily see my truck in inclement weather. Easy insulation on a new tundra and should be for others
